TP-Link AC750 Mesh Wireless N Wall Plugged Range Extender

TP-Link AC750 Mesh Wireless Extender Full Technical Specs:

Hardware Features:

• Interface: 1 x 10/100Mbps Ethernet Port (RJ45)
• Button: Reset Button
• LED Indicator: Power, Signal Strength, Ethernet, WPS
• Antenna: 3 x Internal Antennas

Wireless Features:

• Wireless Standards: IEEE 802.11n/g/b/ac
• Frequency: 2.4GHz and 5GHz
• Signal Rate: Up to 300Mbps on 2.4GHz, Up to 433Mbps on 5GHz
• Reception Sensitivity:
  • 2.4GHz: 270M: -71dBm@10% PER, 130M: -74dBm@10% PER, 108M: -76dBm@10% PER, 54M: -79dBm@10% PER, 11M: -87dBm@8% PER, 6M: -90dBm@10% PER, 1M: -98dBm@8% PER
  • 5GHz: 390M: -60dBm@10% PER, 29.3M: -83dBm@10% PER, 180M: -64dBm@10% PER, 13.5M: -87dBm@10% PER, 78M: -68dBm@10% PER, 6.5M: -90dBm@10% PER, 54M: -75dBm@10% PER, 6M：-90dBm@10% PER
• Transmit Power: < 20dBm (EIRP)
• Wireless Modes: Range Extender, Access Point
• Wireless Functions: Wireless Statistic, Concurrent Mode boost both 2.4G/5G Wi-Fi band, Access Control, LED Control, Domain Login Function
• Wireless Security: 64/128-bit WEP, WPA-PSK / WPA2-PSK

Others:

• Certification: CE, RoHS
• Package Contents: AC750 Wi-Fi Range Extender RE205, Quick Installation Guide
• System Requirements: Microsoft Windows 98SE, NT, 2000, XP, Vista, or Windows 7/8/10, MAC OS, NetWare, UNIX or Linux
