Ubiquiti UniFi AP AC Lite Indoor Access Point (UAP-AC-Lite)

Ubiquiti UniFi AP AC Lite Indoor Access Point (UAP-AC-Lite):

Mechanical

• Dimensions: 160 x 160 x 31.45 mm (6.30 x 6.30 x 1.24 inches)
• Weight: 170 g (6.0 oz)
• Enclosure Material: Plastic
• Mounting: Wall/Ceiling (Kits Included)

Hardware

• Networking Interface: (1) 10/100/1000 Ethernet Port
• Power Method: 802.3af PoE, 24V Passive PoE
• Power Save: Supported
• Maximum Power Consumption: 6.5W
• Max. TX Power: 2.4 GHz: 20 dBm, 5 GHz: 20 dBm
• MIMO: 2.4 GHz: 2×2, 5 GHz: 2×2
• Throughput Rate: 2.4 GHz: 300 Mbps, 5 GHz: 867 Mbps
• Antennas: (2) Dual-Band Antennas, 3 dBi each
• LED: White/Blue

Button

• Reset

Wi-Fi Standards

• 802.11a/b/g/n/ac

Wireless Security

• WEP, WPA-PSK, WPA-Enterprise (WPA/WPA2)

BSSID

• Up to 4 Per Radio

VLAN

• 802.1Q

Advanced QoS

• Per-User Rate Limiting

Guest Traffic Isolation

• Supported

Concurrent Clients

• 250+

Supported Data Rates

• 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
• 802.11b: 1, 2, 5.5, 11 Mbps
• 802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
• 802.11n (WiFi 4): 6.5 Mbps to 300 Mbps (MCS0 – MCS15, HT 20/40)
• 802.11ac (WiFi 5): 6.5 Mbps to 867 Mbps (MCS0 – MCS9 NSS1/2, VHT 20/40/80)
• Operating Temperature
• -10 to 70°C (14 to 158°F)

Operating Humidity

• 5 to 95% Non-condensing

Certifications

• CE, FCC, IC
